Payment Method: | L/C, T/T |
Supply Capacity: | 35sets/Year |
model | Direct heating downstream | Direct heating downstream | Direct heating countercurrent | Direct heating countercurrent | Composite heating | Composite heating |
Material type | ore | HP foaming agent | Blast furnace slag | Thiammonium | Phosphate fertilizer | coal |
Processing capacity (kg/h) | 1,000 | 466 | 15000 | 20000 | 12000 | 5000 |
Water content (%) | 30 | 13 | 6 | 1.5 | 5 | 6.5 |
Final moisture content (%) | 15 | 0.3 | 1 | 0.1 | 0.1 | 0.1 |
Average particle size (mm) | 6.5 | 0.05 | 4.7 | 0.5-1.7 | 0.5 | 5 |
Material accumulation weight (kg/m 3 ) | 770 | 800 | 1890 | 1100 | 1500 | 750 |
Hot air volume (kg/h) | 3900 | 5400 | 10750 | 9800 | 6500 | 16000 |
Inlet gas temperature ( oC) | 600 | 165 | 500 | 180 | 650 | 570 |
Material outlet temperature ( o C) | 42 | 100 | 70 | 80 | 75 | |
heating method | gas | Steam heating | heavy oil | Coal hot stove | heavy oil | heavy oil |
Loading factor | 6.3 | 7 | 7.5 | 7.8 | 18 | |
Speed (rpm) | 4 | 4 | 3.5 | 3 | 4 | 2 |
Tilt | 0.04 | 0.005 | 0.03 | 0.05 | 0.05 | 0.043 |
Copy board number | 12 | twenty four | 12 | twenty two | Inner cylinder outer 8 Inner cylinder outer 16 | 6 12 |
Dryer diameter (m) | 2.0 | 1.5 | 2 | 2.3 | Outer cylinder 2 inner cylinder 0.84 | Outer cylinder 2.4 Inner cylinder 0.95 |
Dryer length (m) | 20 | 12 | 17 | 15 | 10 | 16 |
Drive power (kw) | twenty two | 7.5 | 15 | 11 | 11 | 15 |
