SULI drying equipment specializes in producing belt dryers for Mesh Belt Drying Machine
Features of Multilayer Belt Dryer
1. The hot gas flow passes through the mesh belt and the material layer from bottom to top, thus ensuring uniform heat transfer. This drying machine has high production efficiency and good quality.
2. This multilayer conveyor dryer adopts hoisting equipment with uniform feeder, and the thickness of the material layer can be infinitely variable control.
The adapted materials
can satisfy the drying and mass production of vegetable materials such as roots, stems, and leaves, blocks, flakes, and large particles, and can also retain the nutrients and colors of the products as much as possible.
Drying typical materials are: garlic slices, pumpkin, carrots, konjac, yams, bamboo shoots, horseradish, onions, apples and so on.
Performance characteristics
Drying area, air pressure, air volume, drying temperature, belt speed can be adjusted. To adapt to the characteristics of vegetables and quality requirements.
According to the characteristics of the vegetables, different technological processes can be used and necessary auxiliary equipment can be added.

model	DWC1.6-I ( Loading table)	DWC1.6-II (middlestage)	DWC1.6-III (discharge table)	DWC2-I (loading station)	DWC2-II (middle stage)	DWC2-III (discharge table)
Broadband (m)	1.6	1.6	1.6	2	2	2
Drying section length (m)	10	10	8	10	10	8
Material thickness (mm)	≤100	≤100	≤100	≤100	≤100	≤100
Working temperature (°C)	50-150	50-150	50-150	50-150	50-150	50-150
Heat transfer area (m 2 )	525	398	262.5	656	497	327.5
Steam pressure (Mpa)	0.2-0.8	0.2-0.8	0.2-0.8	0.2-0.8	0.2-0.8	0.2-0.8
Drying time (h)	0.2-1.2	0.2-1.2	0.2-1.2	0.2-1.2	0.2-1.2	0.2-1.2
Transmission power (kw)	0.75	0.75	0.75	0.75	0.75	0.75
Overall size (m)	12×1.81×1.9	12×1.81×1.9	12×1.81×1.9	12×2.4×1.92	12×2.4×1.92	10×2.4×1.92

Single Layer Belt Dryer Machine 50C-150C Spray Drying Plant 0

Company Profile

CHANGZHOU SULI DRYING EQUIPMENT CO.,LTD.is an innovative drying industry enterprises,the state drying equipment,pharmaceutical machinery,chemical and food machinery industry professional production companies.The company has always adhere to the"dedication,inovation,"the purpose of the work,continue to strengthen the development of innocative technological content of products and product currently has a drying,granulation,mixing,crushing nearly a hundred varieties of products.Widely used in pharmaceutial,chemical,food,enzymes,buildingmaterials,electronics,feed,agricultural processing and many other industries,has won the majority of users.
Since its establishment,holding"technology to upgrade the industry,quality and create value"business philosophy,brought together and trained a team of experienced produciton and technical services team,to continuously improve the product,updating and development to ensure that the advanced,high-quality products and good service to customers.
The company of"integrity,timely and thoughful"purpose of business services,through continuous efforts of all employees,will create greater value for you and return!
SuLi company with a variety of sample prototype,welcome friends to visit our small test!

Tags:

Products

MOQ:	1set
Supply Capacity:	200sets/Year

Detail Information

Product Description

Detail Information

Brand Name

SULI

Heating Mode:

Transmission

Material Status:

Granule, Strap, Bulk, Piece Strip

Trademark:

SULI

Specification:

Deponds On The Model

Origin:

Jiangsu, China (Mainland)

Minimum Order Quantity:

1set

Supply Ability:

200sets/Year

Highlight

belt dryer machine 50c

150c spray drying plant
