| Supply Capacity: | 600sets/Year |
working principle:
The so -called vacuum drying is to heat the drying material under vacuum conditions for heating and drying. If the vacuum pump is used to use the vacuum pump, the drying speed is accelerated.
Note: If the condenser is used. The solvents in the material can be recycled by condenser. If the solvent is water, no condenser can save energy investment.
Performance characteristics:
◎ The boiling point of the material solution under the vacuum is reduced. Increase the heat transfer driving force of evaporator. Therefore, a certain heat transfer can save the heat transfer area of the evaporator.
◎ The heat source of evaporation operation can be low -pressure steam or waste heat steam.
◎ The evaporator has less heat loss.
◎ Disinfection treatment can be performed before drying. There are no unsustaining in the process of drying, which meets the GMP requirements.
◎ It is a static vacuum dryer. Therefore, the shape of the dry material will not be damaged.
Adapt to materials:
It is suitable for the low temperature and drying of thermal materials that are easy to break down at high temperature, aggregate and deteriorated; it is widely used in industries such as pharmaceuticals, chemicals, food, electronics.
Technical specification
| Name | FZG-10 | FZG-15 | FZG-20 |
| Drying box size | 1500×1060×1220 | 1500×1400×1220 | 1500×1800×1220 |
| Dry box size | 1513×1924×1720 | 1513×1924×2060 | 1513×1924×2500 |
| Baked layer | 5 | 8 | 12 |
| Laminate | 122 | 122 | 122 |
| Baking size | 460×640×45 | 460×640×45 | 460×640×45 |
| Baking | 20 | 32 | 48 |
| Pressure in the rack pipe | ≤0.784 | ≤0.784 | ≤0.784 |
| Baketing temperature | 35-150 | 35-150 | 35-150 |
| The empty load in the box | -0.09～0.096 | ||
| When -0.1MPa, when the heating temperature is 110℃, the gasification rate of wate | 7.2 | 7.2 | 7.2 |
| When using condenser, vacuum pump model, power | 2X-70A / 5.5KW | 2X-70A / 5.5KW | 2X-90A / 2KW |
| When no condenser, vacuum pump model, power | SK-3 / 5.5KW | SK-6 / 11KW | SK-6 / 11KW |
| Dry box weight | 1400 | 2100 | 3200 |
Note: The water ring type vacuum pump is used by the voltage volume to increase the vacuum.
Precautions
◎ When ordering, please select the appropriate vacuum dryer according to factors such as the water content of the dry material, the water content of the temperature, the dry amount of the temperature, the dry amount of the drying amount of the temperature. In the same type of vacuum dryer, there are four heating methods: steam thermal water guide thermal oil, respectively. For example, in order to increase the amount of drying, please increase the number of drying layers in time.
◎ The attachments in the vacuum drying system in the instructions of the instructions can provide and install it for users. Please explain when ordering.
◎ This division can provide design, manufacturing and installation for special requirements in the vacuum drying system proposed by users.
◎ The quality of this device implements the quality of the user. All accessories are provided for a long time, please rest assured.
|
|
